MonoFlange Valves
We design and manufacture a range of Mono Flange Valves that is used on upstream offshore or onshore gas and oil production and initial processing installation. Manufactured using high quality raw material along with steel and brass, these valves are pressure tested to provide complete leakage proof function. Our product range is in great demand due to their fine quality and can be fabricated as per the requirement.
MonoFlange Valves
We offer a range of MonoFlange Valves with screwed bonnet design. Standard material used to manufacture these valves is carbon Steel with an optional material which includes Super Duplex, Alloy 20, Titanium and Zirconium. These Monoflange Valves are one piece rugged construction which gives less probability of corrosion and longer life. These valves are typically used on gas gauge pressure instrument applications to reduce the size and weight of the pipe-valve assemblies used for primary and secondary isolation, vent and calibration.
MonoFlange Valves
We offer a range of MonoFlange Valves with screwed bonnet design. Standard material used to manufacture these valves is carbon Steel with an optional material which includes Super Duplex, Alloy 20, Titanium and Zirconium. These Monoflange Valves are one piece rugged construction which gives less probability of corrosion and longer life. These valves are typically used on gas gauge pressure instrument applications to reduce the size and weight of the pipe-valve assemblies used for primary and secondary isolation, vent and calibration.
| BONNET ASSLY. FEATURES : | |
| Design | |
| Screwed bonnet | |
| Bonnet | |
| Back seat blowout proof | |
| Stem | |
| Rolled stem operating threads. | |
| Stem tip | |
| Self centering non rotating, rotating, regulatingand soft seated | |
| Bonnet Pusher | |
| Silver plated for anti galling freezing for increased stem cycle life | |
| Dust Cap | |
| Protects stem
threads from ingrease of contamination. Colour coded identification. |
|
| Handle | |
| Low torque operating | |
| Sealing | |
| Leak tight seal for easy operation of valve. |
| SPECIFICATIONS : | ||
| Size | 1/4", 3/8", 1/2" | |
| End ports | NPT, BSPT, socket weld | |
| Process flange size | 1/2",3/4",1",1-1/2", 2" | |
| Flange pressure rating | 150#, 300#, 600#, 900#, 1500#, 2500# | |
| Flange end | Raise Face. Ring Joint | |
| Bleed port | 1/4", 3/8", 1/2" | |
| Version | Straight & angle | |
| Max. Std. Pressure | 6000 Psi (413 Bar) | |
| Temperature Rating | PTFE 450° F (232°
C) Grafoil 700° F (371° C) |
|
| Material | SS 316, SS 304, C.S., F11, Hastelloy, Monel | |
| Standard seat | Ø4mm | |
| Panel mount option | All valves are 100% Factory tested prior to shipment. | |
 |
